Ocean Optics(Ocean Insight) 제품인 Adapters



* 사진을 클릭하면 더 크게 보실 수 있습니다



Ocean Optics(Ocean Insight) Adapters Specifications



Item	Description	Product Details	External Threads
ADP-SMA-SMA	This 3 mm Suprasil rod mates in-line with two SMA 905-terminated optical fibers.	As light passes through it, the core modes injected from the first fiber are mixed, while cladding modes are stripped prior to coupling into the second fiber.
C-MOUNT-MIC	SMA-905 microscope or telescope adapter	This adapter allows SMA 905-terminated optical fibers to be connected seamlessly to the C-mount port of a microscope or telescope so that light can be routed to a spectrometer for full spectral analysis. The lens mount is for 1″ optic with usable depth of 0.5.
FCBARREL	Threaded for compatibility with FC connectors	This handy barrel allows you to convert many of our accessories for use with FC-terminated fibers. Simply replace the existing inner SMA barrel in your lens, lamp, or other fixture with this barrel threaded for FC connectors, then realign. Barrel Outer Diameter: 6.35 mm (1/4″)	M8-0.75
MFA-C-MOUNT	Adapter	This adapter allows 6.35 mm (1/4″) diameter optical fiber probes to be connected seamlessly to the C-mount port of a microscope or telescope so that light can be routed to a spectrometer for full spectral analysis.
MFA-PT	Adapter	This adapter allows SMA 905-terminated optical fibers to be connected seamlessly to a phototubus outlet on a microscope so that light from withinthe microscope’s field of view can be routed to a spectrometer for spectral analysis.
